View UEFA-Compliant Stadium Perimeter LED Display for Professional Sports Venues. Engineered for efficiency, this perimeter LED display uses larger cabinet sizes to increase installation speed while reducing labour costs.

UEFA-Compliant Stadium Perimeter LED Display for Professional Sports Venues

This UEFA-compliant stadium perimeter LED display is purpose-built for professional sports venues and football stadiums, meeting strict safety and performance standards. Designed for reliable use across different sporting environments, it features quadruple protection including soft module masks and impact-absorbing rubber pads to significantly reduce player injury risks. A specialised safety structure allows the perimeter screen to be quickly moved aside, forming an emergency access exit when required.

Fast Installation, Intelligent Design and Uninterrupted Operation



Engineered for efficiency, this perimeter LED display uses larger cabinet sizes to increase installation speed while reducing labour costs. Fast interlock mechanisms enable quick lock-and-go splicing, while support for both front and rear maintenance simplifies servicing. Purpose-designed transport dollies, matched to cabinet dimensions, allow fast movement, space-saving stacking, and one-press disassembly. An N+1 power supply backup combined with dual receiving card redundancy ensures continuous operation without blackout during live events.

Broadcast-Ready Visual Performance with All-Weather Protection

Delivering exceptional image quality, the stadium LED screen features a 7680 Hz refresh rate, a 6000:1 contrast ratio, and brightness levels up to 6000 nits for smooth playback and excellent in-camera visuals during live broadcast and streaming. A wide 140° horizontal viewing angle ensures consistent visibility from all seating areas. With IP65-rated waterproof protection on both the front and rear, the display performs reliably in all weather conditions.


Product Specifications


7680
Refresh Rate
6000
Brightness
5,500-9,500(Adjustable)
Color Temperature
160/120
Viewing Angle
6000:1
Contrast Ratio

SMD - Configuration & Packaging
80 X 48 - Module Resolution
Front And Rear Access - Accessibility
IP65 - IP Rating
100000 - LED Lifetime
SMD - Configuration & Packaging
60 X 36 - Module Resolution
Front And Rear Access - Accessibility
IP65 - IP Rating
100000 - LED Lifetime
SMD - Configuration & Packaging
50 X 30 - Module Resolution
Front And Rear Access - Accessibility
IP65 - IP Rating
100000 - LED Lifetime
SMD - Configuration & Packaging
40 X 30 - Module Resolution
Front And Rear Access - Accessibility
IP65 - IP Rating
100000 - LED Lifetime
